VSI Series Vertical Shaft Impact Crusher
【Max Feed】 ≤50mm 【Capacity】 60-640t/h
Key words:
Category:
Vertical shaft impact crusher series
Brief Introduction:
Applications:
Suitable Material:
VSI Series Vertical Shaft Impact Crusher
Advantages
The material falls vertically from the upper part of the machine into the impeller of high-speed rotation. Under the action of high-speed centrifugal force, the material that is shunted around the impeller in another part of the machine produces high-speed impact and pulverization. After the materials collide with each other, they will be in the impeller and Between the casings, the vortex is formed by multiple collisions, friction and pulverization, and is discharged straight from the lower part to form a closed circuit for multiple cycles, and the required size of the finished product is controlled by the screening device.
|
Model |
Maximum feed port size （mm） |
Processing capacity (t/h) |
Spindle speed (r/min) |
Power (kw) |
Dimensions （L*W*H) (mm) |
||
|
Soft material |
Hard material |
Waterfall and center feeding |
Whole center feed |
||||
|
VSI-7611 |
35 |
30 |
120-180 |
60-90 |
1710-1900 |
55×2 |
3600*2248*2533 |
|
VSI--8515 |
45 |
35 |
200-260 |
100-130 |
1520-1720 |
90×2 |
4378*2350*2667 |
|
VSI-9526 |
45 |
40 |
300-380 |
150-190 |
1350-1530 |
132×2 |
4640*2650*2800 |
|
VSI-1140 |
50 |
45 |
450-520 |
225-260 |
1170-1350 |
200×2 |
5000*2700*3300 |
|
VSI-1145 |
50 |
45 |
500-640 |
250-360 |
1100-1310 |
220×2 |
5100*2790*3320 |
