PYS-B Standard Simmons Cone Crusher
【Max Feed】 ≤460mm 【Discharging Opening】 9-64mm 【Capacity】 40-1498t/h
Key words:
Category:
Cone crusher series
Brief Introduction:
Applications:
Suitable Material:
PYS-B Standard Simmons Cone Crusher
Advantage
The electric motor drives the big and small gears by belt pulley to make the crushing wall do cranking. When the material passes the crushing wall and rolling mortar wall(fixed wallboard), it is extruded, twisted and crushed. According to the lamination theory, the material texture is broken and ground under the forces of the many directions, and finally it is shaped into the building stones that meet the requirements.
Cone Crusher Spare Parts
Horizontal Countershaft, Eccentric bush, fixed cone, movable cone, bearing and so on. The spare parts are applied for the casting and forging technology and are made from high manganese steel, high chromium and so on.
|
Model
|
Specification
|
Chamber Size
|
Feeding port size inch (㎜) |
Discharge port adjustment range (㎜) |
Power （kw） |
Equipment weight
(ton) |
Capacity (t/h) |
|
|
Closed edge |
Open side |
|||||||
|
PYS-B0910 PYS-B0917 PYS-B0918 |
3Ft |
Fine Coarse Extra Coarse |
3 5/8 (83) 6 3/8 (159) 6 1/2 (163) |
4 1/8 (102) 7 (175) 7 1/8 (178) |
9-22 13-38 25-38 |
75 |
14.64 |
40-100 55-180 105-180 |
|
PYS-B1313 PYS-B1321 PYS-B1324 PYS-B1325 |
4 1/4 Ft |
Fine Medium Coarse Extra Coarse |
4 3/8 (109) 7 1/2 (188) 8 5/8 (216) 9 5/8 (238) |
5 3/89(137) 8 1/4 (210) 9 5/89 (241) 10 3/8 (259) |
18-31 16-38 19-51 25-51 |
155 |
25.86 |
100-200 118-280 155-384 212-390 |
|
PYS-B1620 PYS-B1624 PYS-B1626 PYS-B1636 |
5 1/2Ft |
Fine Medium Coarse Extra Coarse |
7 1/2 (188) 8 1/2 (213) 9 5/8 (241) 13 1/4 (331) |
8 3/8 (209) 9 5/8 (241) 10 3/4 (269) 14 1/2 (368) |
16-38 22-51 25-64 38-64 |
240 |
50.8 |
162-360 232-460 270-698 388-745 |
|
PYS-B2127 PYS-B2133 PYS-B2136 PYS-B2146 |
7FtHD |
Fine Medium Coarse Extra Coarse |
10 1/8 (253) 12 1/8 (303) 13 3/5 (334) 18 1/8 (425) |
11 1/8 (278) 13 3/8 (334) 14 3/4 (369) 18 1/8 (460) |
19-38 25-51 31-64 38-64 |
380 |
89.5 |
344-798 550-1098 710-1398 800-1498 |
