PC Hammer Crusher
【Max Feed】 ≤1000mm 【Discharging Opening】 0-60mm 【Capacity】 20-680t/h
Key words:
Category:
Hammer crusher series
Brief Introduction:
Applications:
Suitable Material:
PC Hammer Crusher
Advantages
The electrical motor drives the crusher shaft and make the movable jaw move upwards and downwards. This movement would trigger the toggle plate to push the movable jaw forward and backwards.When the movable jaw moves forth toward the fixed jaw, materials in the crushing cavity will be squashed or chopped. And the movable jaw travels back, the chopped or squashed materials which met the requirement will be discharged from the outlet. Since the motor keeps working, the crusher will crush and discharge periodically to achieve mass production
|
Model |
Feed particle size≤(mm) |
Discharge gap (mm) |
Production (t/h) |
Motor Power (KW) |
|
PCφ800*800 |
500 |
≤10-60 |
40-60 |
45 |
|
PCφ800*1000 |
500 |
≤10-60 |
50-80 |
55 |
|
PCφ1000*1000 |
550 |
≤10-60 |
60-100 |
75 |
|
PCφ1000*1200 |
550 |
≤10-60 |
80-120 |
90(45+45) |
|
PCφ1000*1400 |
550 |
≤10-60 |
100-150 |
110(55+55) |
|
PCφ1000*1800 |
550 |
≤10-60 |
100-160 |
132 |
|
PCφ1200*1400 |
550 |
≤10-60 |
130-180 |
132(75+75) |
|
PCφ1200*1500 |
550 |
≤10-60 |
150-200 |
132(75+75) |
|
PCφ1200*1800 |
550 |
≤10-60 |
180-280 |
200 |
|
PCφ1500*1800 |
650 |
≤10-60 |
180-400 |
200(110+110) |
|
PCφ1500*2000 |
650 |
≤10-60 |
200-450 |
250-280 |
|
PCφ1800*2000 |
700 |
≤10-60 |
240-680 |
500(250+250) |
|
PCXφ1400*1200 |
100 |
≤12 |
80-120 |
160-200 |
